GraphRAG-SDK

Build intelligent GraphRAG applications with FalkorDB and LLMs

• Ingest raw documents (text, PDF, Markdown) directly into a FalkorDB knowledge graph with schema-guided entity extraction.
• Retrieve cited answers via a hybrid pipeline that combines vector search, full-text search, Cypher generation, and relationship expansion.
• Update the graph incrementally on PR merges with apply_changes() — re-sync individual documents without rebuilding.
• Plug in any LLM or embedder via LiteLLM (OpenAI, Azure, Anthropic, Gemini, Groq, Cohere, local models, etc.).
• Benchmark-leading accuracy — the top score on GraphRAG-Bench across both multi-document and single-document question sets. See benchmark methodology and results.

Resources:

• GraphRAG-SDK GitHub Repository
• Examples — runnable starters covering quick start, schemas, custom strategies, and incremental updates
• API Reference

Guide	Description
Getting Started	Step-by-step tutorial from install to first query
Architecture	Pipeline design, graph schema, retrieval strategy
Configuration	Connection, providers, and tuning reference
Strategies	All ABCs and built-in implementations
Providers	LLM and embedder configuration guide
Benchmark	Methodology, results, and reproduction instructions

Quick Start

Install and start FalkorDB

pip install graphrag-sdk[litellm]
docker run -d -p 6379:6379 -p 3000:3000 --name falkordb falkordb/falkordb:latest
export OPENAI_API_KEY="sk-..."

For PDF ingestion, install the pdf extra instead: pip install graphrag-sdk[litellm,pdf].

Or sign up for FalkorDB Cloud.

Ingest and query

import asyncio
from graphrag_sdk import GraphRAG, ConnectionConfig, LiteLLM, LiteLLMEmbedder

async def main():
    async with GraphRAG(
        connection=ConnectionConfig(host="localhost", graph_name="my_graph"),
        llm=LiteLLM(model="openai/gpt-4o-mini"),
        embedder=LiteLLMEmbedder(model="openai/text-embedding-3-large", dimensions=256),
    ) as rag:
        # Ingest raw text (or pass a file path for .md / .txt / .pdf)
        result = await rag.ingest(
            text="Alice Johnson is a software engineer at Acme Corp in London.",
            document_id="my_doc",
        )
        print(f"Nodes: {result.nodes_created}, Edges: {result.relationships_created}")

        # Finalize: deduplicate entities, backfill embeddings, build indexes
        await rag.finalize()

        # Full RAG: retrieve + generate with provenance
        answer = await rag.completion("Where does Alice work?")
        print(answer.answer)

asyncio.run(main())

Define a schema (optional)

A schema constrains which entity and relation types the extractor produces. Without one the SDK runs open-world extraction; with one you get a tighter, more queryable graph.

💡 Schema vs. ontology: the SDK’s GraphSchema is the concrete, code-level implementation of the broader concept often called an “ontology” in knowledge-graph literature — a controlled vocabulary of entity and relation types. This page uses schema throughout because that’s the actual class and parameter name in the API (GraphSchema, schema=...); reach for “ontology” only when discussing the conceptual design behind a schema.

from graphrag_sdk import GraphSchema, EntityType, RelationType

schema = GraphSchema(
    entities=[
        EntityType(label="Person", description="A human being"),
        EntityType(label="Organization", description="A company or institution"),
        EntityType(label="Location", description="A geographic location"),
    ],
    relations=[
        RelationType(label="WORKS_AT", description="Is employed by", patterns=[("Person", "Organization")]),
        RelationType(label="LOCATED_IN", description="Is situated in", patterns=[("Organization", "Location")]),
    ],
)

async with GraphRAG(
    connection=ConnectionConfig(host="localhost", graph_name="my_graph"),
    llm=LiteLLM(model="openai/gpt-4o-mini"),
    embedder=LiteLLMEmbedder(model="openai/text-embedding-3-large", dimensions=256),
    schema=schema,
) as rag:
    ...  # ingest / completion as above

Incremental Updates

Re-sync individual documents without rebuilding the graph. The canonical CI use case is updating the graph on PR merge — added, modified, and deleted files in one batch:

async with GraphRAG(connection=ConnectionConfig(...), llm=..., embedder=...) as graph:
    result = await graph.apply_changes(
        added=["docs/new_feature.md"],
        modified=["docs/api.md"],
        deleted=["docs/removed_page.md"],
    )
    await graph.finalize()  # once per batch — finalize is O(graph size)

    # Per-file outcomes are wrapped in BatchEntry — the batch never raises.
    for entry in result.added + result.modified + result.deleted:
        if not entry.is_success:
            print(f"failed: {entry.error_type}: {entry.error}")

The three primitives behind the wrapper:

Method	When to use
update(source, document_id=...)	Document content changed. A SHA-256 content hash short-circuits no-op updates (touch-only PRs cost ~1 Cypher query). Pass if_missing="ingest" for upsert semantics.
delete_document(document_id)	Document removed. Cleans up entities orphaned by the deletion; preserves entities still referenced by other documents.
apply_changes(added=..., modified=..., deleted=...)	Heterogeneous batch. Per-file errors are collected, not raised. Does not call finalize() — caller drives that cadence.

Cost model. finalize() runs cross-document deduplication, which scans the full entity table — its cost is O(graph size), not O(change size). Embedding backfill within finalize() is O(change size) — only nodes/edges missing embeddings get touched. For CI use cases, batch all PR changes through apply_changes and call finalize once at the end of the run, not per file — per-file finalize multiplies the dedup constant by the number of files touched.

Crash safety. update() uses an idempotent rollforward cutover: new content is written to a __pending__ document, a single atomic Cypher statement marks it ready_to_commit=true, then the live document is replaced. A crash before the marker discards the pending write on retry; a crash after the marker rolls forward to completion. Retrying the same update() call is always safe.

Concurrency. apply_changes exposes max_concurrency (adds, default 3) and update_concurrency (modifies, default 1). Updates default to 1 because orphan-cleanup correctness under concurrent updates depends on a pipeline-ordering invariant — raise it only if you’ve verified your concurrent updates never share an entity.

Key Features

• Schema-guided extraction — Constrain the entity and relation types the LLM produces, or run open-world if you don’t have a schema yet.
• Hybrid retrieval — Vector search, full-text search, Cypher generation, and relationship expansion combined in one pipeline.
• Cited answers — Every answer is traceable to its source chunks via MENTIONS edges; pass return_context=True to completion() to get the retrieval trail.
• Incremental updates — apply_changes() handles added/modified/deleted documents in one call, with crash-safe rollforward cutover.
• Multi-tenant — graph_name on the connection provides per-tenant isolation in a single FalkorDB instance.
• Provider-agnostic — Any LLM or embedder reachable via LiteLLM works out of the box; custom providers plug in behind clean ABCs.

Getting the retrieval trail behind an answer

answer = await rag.completion("Where does Alice work?", return_context=True)
print(answer.answer)
for chunk in answer.context.chunks:
    print(chunk.document_id, chunk.text)

Examples

Runnable starters live in graphrag_sdk/examples:

#	Example	What you’ll build
1	Quick Start	Your first ingest-and-query loop in under 30 lines
2	PDF with Schema	A PDF Q&A bot with your own entity and relation types
3	Custom Strategies	The benchmark-winning pipeline, ready to drop in
4	Custom Provider	Plug in any LLM or embedder behind a clean interface
5	Notebook Demo	An interactive walkthrough that shows the provenance trail
7	Incremental Updates	update, delete_document, and apply_changes for CI-driven graph syncs

How it works

1️⃣ Ingest documents into a knowledge graph

• Document loading: Markdown, plain text, and (with the pdf extra) PDF inputs go through structural-aware chunkers.
• Entity extraction: An LLM-driven extractor reads each chunk, optionally constrained by your schema.
• Resolution: Surface forms of the same entity are merged via exact-match plus optional LLM-verified resolution.
• Provenance: Chunks, entities, and relationships are connected by PART_OF, NEXT_CHUNK, and MENTIONS edges so every answer can be traced back to its source text.

2️⃣ Retrieve relevant context

• Vector search ranks chunks and entities by embedding similarity.
• Full-text search complements vectors with keyword precision.
• Cypher generation (experimental) lets the LLM emit graph queries directly for aggregate or structural questions.
• Relationship expansion traverses the graph from the seed hits to surface multi-hop context.
• Reranking orders the final passages by cosine similarity to the question.

3️⃣ Generate cited answers

• Retrieval-grounded completion combines the retrieved context with the user’s question and feeds it to the LLM.
• Source attribution is built into the response — every answer points back to the chunks that supported it.

📓 Understanding Ontologies and Knowledge Graphs
